CP-Z800
Product Application
Specifications
| Round bottle labeling machine | Parameter |
|---|---|
| Labeling capability | 30-150pcs/min |
| Applicable bottle size | ￠30≤diameter≤￠80mm |
| Applicable label size | 15≤H≤120mm，20≤L≤200mm |
| Bidding speed | MAX 25m/min |
| Labeling accuracy | ±1mm |
| Applicable label specifications | Glazin backing paper, opaque (transparent labels need to be made with light eyes) |
| Inside diameter of the label volume | 76mm |
| Machine size (L * W * H) | <350mm |
| total power | 1200W |
| power supply | AC220V 50/60Hz 1P |
| Overall dimension | 2000×1200×1500mm |
Features
Horizontal standing bottle feeding system ensures stable feeding and easy operation.
Wheel attachment roll the bottle body to make the label attach more firmly.
Touch man-machine operation interface, abnormal situation can be displayed on the man-machine interface. There are 50 groups of memory functions, and no need to reset the replacement of different specifications of products.
Label stripping distance is calculated automatically by marking motor, label detection photoelectric and PLC. Different label lengths can be modified on the man-machine interface, which is convenient to use.
No mark, broken mark, missing mark, colorless belt alarm and automatic stop, no bottle without labeling.
Stable and durable frame and various parts, are standardized modular design, easy to replace parts and meet the labeling requirements of different bottle types.
