CP-ZL900
It is suitable for independent and multi row packaging: rectangular, oblate, semicircular and other materials, such as chocolate, nougat, candy cubes, leisure food and other regular materials.
Product Application
Specifications
| CP-ZL900 | Parameter |
|---|---|
| packaging speed | 100 - 1000 bags/minute |
| packaging film range | Maximum diameter 390mm, Maximum width 250mm |
| package specification | Length 20 - 1 50mm, Width 1 0 - 60mm, Thickness 5 - 30mm |
| Motor power | 9.6KW |
| Machine dimensions | 8700mm * 1 o00mm * 1 700mm |
| Machine weight | 21 50kg |
| Machine power supply | 380V 50Hz |
| Film | - |
Features
- Machine shell : all 304 stainless steel wire drawing plate (article contact surface 304)
- Equipped with servo motor and PLC Operating system of international famous brand , it ensures the stability, high speed and high accuracy of the machine under high-speed operation , and has strong anti – interference expansion capability, which can be connected to MESTintel system
- Water circulation structure is adopted for chocolate and coated products to protect chocolate products from melting during packaging o The design of longitudinal sealing and preheating block ensures the sealing effect of equipment under high-speed operation
- The equipment is equipped with a remote control system , which can more easily solve the problems and upgrade the functions of the control system
